Hikvision DS-K1107AMK Card reader MiFare + code keys

The DS-K1107AMK is a card reader from Hikvision's access control line, which also features code keys to open a door or gate. The card reader can be connected via RS-485 or Wiegand. The card reader can read MiFare cards and can be connected to Hikvision's Basic+ and Pro Complete door controllers.

EM vs MiFare

Hikvision supplies card readers with the ability to read either EM or MiFare. This choice is made in the reader and cannot be changed via software. MiFare has a heavier encryption. If other EM solutions are already present, EM can also be selected Important features

Kenmerken
- Brand: Hikvision
- Model: DS-K1107AMK
- ID settings: setting with the DIP switch on the motherboard
- Card reading distance: EM card: ≤100 mm (≤3.94″) Mifare card:≤50 mm (≤1.97″)
- Processor: 32-bits
- Keyboard: no keyboard (DS-K1107E and DS-K1107M)
- Keyboard with 12 keys (0~9, *, #) (DS-K1107EK and DS-K1107MK)
- Communication interface: RS-485 / Wiegand (DIP switch)
- Audio alert: beeper
- Power supply: 12VDC
- Power consumption: ≤2W
- LED indicator: power indicator; Status LED indicator
- Temper resistant: support
- Installation: Wall mounting with screws. The Gang Box is not supported.
- Protection level: IP 65
- Working humidity: 10% to 90% (non-condensing)
- Operating temperature: -20°C to +65°C (-4°F to +149°F)
- Dimensions (L × W × H): 115 × 44 × 22 mm (4.53 × 1.73 × 0.87 inches)
- Colour: Grey
